IPF 610
Photo 1 en taille normale

    Le IPF 610 1 Le IPF 610 2 Le IPF 610 3 Le IPF 610 4

  Price :
2000.00 € (Suggested Price)

Product description :
The Canon imagePROGRAF iPF610 24" large format printer produces vibrant full-bleed posters, clear text documents and crisp line drawings easily and quickly. Its 24" output will impress clients and colleagues by communicating visual layouts with eye-catching color and exacting details. The imagePROGRAF iPF610 features a Reactive Ink system consisting of four highly colorfast dye inks - Cyan, Magenta, Yellow and Black - plus two channels of pigment-based matte black.

The new imagePROGRAF iPF610 has a large LCD panel and operates with a reduced amount of noise, which means greater ease of operation and more flexibility in various environments. The iPF610 provides both quality and performance, demanded by today's market with the L-COA controller - the brain of the imagePROGRAF iPF series. The L-COA controller, alongside the 5-color Reactive Ink system, is designed to drive the best quality output at the highest possible speeds. The iPF610 has on-board support for HP-GL/2 and HP RTL files. It prints on a variety of media plus the inclusion of printing/application software programs provides the versatility and flexibility needed to be used in a wide variety of industries and applications, all in one captivating package.

* 5-Color Dye/Pigment Reactive Ink technology: Consisting of Cyan, Magenta, Yellow, Black dye ink and two channels of pigment Matte Black
* HPGL-2 and HP RTL Support
* Two Matte Black Ink Tanks: Doubling the matte black is used for maximum black density and speed
* Print-Head with FINE technology: Incorporates an ultra high-density 15,360 nozzle print head with ultra small ink drops (4 pl), delivering smooth and beautiful gradations
* Multiple Media Options: Four-Way multi-feed enables numerous paper options: roll, cassette, manual front feed and manual top feed
* Borderless Printing: Four-sided edge-to-edge printing, only with roll media
* Non-firing Detection and Compensation Function: When clogged or non-firing nozzles are detected, the print-head cleaning cycle is automatically executed. If the nozzle remains obstructed, the iPF610 will automatically compensate by re-routing the ink to functioning nozzles


5 Color Reactive Ink System
spacer
The Reactive ink system consists of four highly colorfast dye color inks and two channels of matte black pigment ink. Doubling the matte black is used for high-speed printing of line drawings and text-oriented office documents. When printing, four of the colors may be applied at the same time, since matte black or black is automatically selected based on the media type selected in the printer driver. Matte black will be used when printing on plain or matte media whereas the dye-based black will be used when printing on coated or glossy paper. The unique reactive ink formulation also provides improved resistance against scratches and marks when compared to conventional dye inks.
Multiple Media Options
spacer

1. Roll
2. Cassette
3. Manual Front Feed
4. Manual Top Feed

With the iPF610 all media loading can be accessed from the front of the printer; there is no necessity for the user to go behind the printer in order to load paper. For ease of use, an automatic media switching feature has been added, keeping the workflow speed on par with the printer. Media switching is done within the printer driver and doesn't require the user to physically go to the printer to make a change. Its manual top-feeding design improves performance, while a refined printing sequence delivers accelerated throughput overall. The iPF610 supports a media thickness of up to 1.5mm through the front manual feed.



Features
Printer Type
5-Color 24-inch Printer
Number of Nozzles
Total: 30,720
MBK: 5,120 nozzles
C, M, Y, BK: 2,560 nozzles each
Nozzle Pitch
1,200 dpi

Non-firing nozzle detection and compensation
Print Resolution (Up to)
2,400 x 1,200 dpi (Max)
OS Compatibility
Windows®(2000/XP/Vista 32/64bit)
MAC(OS9,OS10)1
Standard Interface
USB 2.0 High-Speed
10/100 Base-T/TX
Optional: IEEE 1394 (Firewire®)
Ink Droplet Size
4 picoliter
Ink Capacity
130ml per color2
Ink Types
Dye/Pigment Reactive Ink
Color Set
Dye: Cyan, Magenta, Yellow, Black
Pigment: Matte Black (two channels)
Buffer/Ram
256 MB
Hard Drive
N/A
Media Width
Cut Sheet and Roll: 8" - 24"
Cassette: 8" - 17"
Media Thickness
Top Loading Manual Feed: 0.07 - 0.8mm (2.8 - 31.4mil)
Front Loading Manual Feed: 0.5 - 1.5mm (19.6 - 59.0mil)
Roll: 0.08 - 0.8mm (2.8 - 31.4mil)
Cassette: 0.08 - 0.3mm (3.2 - 11.8mil)
Maximum Roll Print Length
59 Feet (18 meters)3
Maximum Media Roll Diameter
5.9" (150mm)
Borderless Printing Width (Roll Media Only)
10" (254 mm), B4 (257 mm), A3+ (329 mm), 14" (356 mm), 16" (407 mm), A2 (420 mm), A2+/17" (432 mm), B2 (515 mm), A1 (594 mm), 24" (610 mm)
Paper-Feed Method
Roll Feed: One Roll, front output
Top Loading Manual Feed: One sheet, front output
Front Loading Manual Feed: One sheet, front output
Cassette: Up to 250 Sheets (Letter, Plain Paper), front output
Languages
Language: GARO (Canon Proprietary)
Noise Level (Approx.)
Operation: 52 dB (A) or less
Standby: 35 dB (A) or less
Acoustic Power: 6.6 Bels
Physical Dimensions
38.9" (H) x 39.3" (W) x 39" (D)
Weight
Approximately 149.9 lbs with stand
Power Source
AC-100-120V (50-60Hz)
Power Consumption
Maximum: 100W or less
Standby 6W or less
Power Off: 1W or less (Compliant with Executive Order)
Operating Environment
Temperature: 59°-86° F (15° - 30° C)
Relative Humidity: 10-80% (No Condensation)
User-replaceable items
Print Head (PF-03), Maintenance Cartridge (MC-16)
Software Included
Canon Printer Driver, Digital Photo Front-Access, Printer Driver Extra Kit (Free Layout, imageRUNNER Linking Function), HDI Driver for AutoCAD4
