IPF 605
Photo 1 en taille normale

    Le IPF 605 1 Le IPF 605 2 Le IPF 605 3 Le IPF 605 4

  Price :
1600.00 € (Suggested Price)

Product description :
This imagePROGRAF iPF605 is designed to support the printing needs of technical document users working with Computer-Aided Design (CAD), GIS (Geographic Information Systems), and AEC (Architecture, Engineering, and Construction) applications as well as users in general office environments. The iPF605 joins the iPF610 as part of Canon's 24-inch printer portfolio, sharing much of the same advanced technology. The included PosterArtist Lite - poster creation software gives the user the ability to quickly and easily create professional large format prints. Aimed to be an affordable solution, for personal and small workgroup users producing large format technical drawings, the streamline iPF605 does not offer a cassette tray.

The iPF605 printer helps make large format printing easier than ever with included workflow software such as the new PosterArtist Lite- Poster Creation Software, Canon's Printer Driver for Windows and Macintosh, with a Free Layout feature for host-based nesting, Real Preview for real-time viewing to allow users to modify settings before “Print” is selected, and the powerful imageRUNNER Enlargement Copy feature for enlarging documents scanned on a Color imageRUNNER device with Universal Send. The iPF605 printer supports the widely available HP-GL/2 and HP-RTL page description languages and also includes an AutoCAD® HDI Driver, and Digital Photo Front-Access software for easy photo printing from digital cameras.

The iPF605 is well positioned to fulfill the divers needs of the different markets it is tailored to, with PosterArtist Lite users simply follow the programs 4 easy steps to create posters that can be used in applications such as Office presentation, Trade shows, Retail signage and much, much more. The PosterArtist QuickCopy feature provides easy solution for CanoScan desktop scanner to be used as copier, making a letter-size flyer and documents into a full-size poster with a touch of a button. The printer has amazing printing speed, taking as little as 33 seconds1 to complete an A1-sized full-density color plot (33.1 x 23.4 inches). This incredible speed is enabled by Canon's advanced PF-03 print head with 1.07 inch print swaths, and equipped with 2,560 nozzles per color (C, M, Y, K) with 5,120 nozzles for matte black.

Reactive Ink Technology
spacer
Ideal for technical applications, Canon's breakthrough 5-color dye/pigment Reactive Ink technology utilizes four highly colorfast dye inks for producing bold, expressive color plus two channels of matte black ink for printing precise lines, smooth curves and small text on technical and office documents. These Canon inks provide superior adhesion to media, scratch and marker resistance and ensure minimal "bleeding" between colors and text. Even small text printed on colored backgrounds or on uncoated technical papers is crisp and legible.
L-COA Processor
spacer
Canon's L-COA (Large Format Printer COmmon Architecture) print controller is the "brain" that powers the printers' data. This unique, high-speed processor drives the print engine to lay ink down with high precision and helps ensure optimal image quality and color accuracy. This processor enables the print system to process large volumes of data while optimizing output of complex high-color GIS images and architectural renderings for maximum readability and color accuracy.



Features
Printer Type
5-Color 24-inch Printer
Number of Nozzles
Total: 30,720
MBK: 5,120 nozzles
C, M, Y, BK: 2,560 nozzles each
Nozzle Pitch
1,200 dpi

Non-firing nozzle detection and compensation
Print Resolution (Up to)
2,400 x 1,200 dpi (Max)
OS Compatibility
Windows®(2000/XP/Vista 32/64bit)
MAC(OS9,OS10)1
Standard Interface
USB 2.0 High-Speed
10/100 Base-T/TX
Optional: IEEE 1394 (Firewire®)
Ink Droplet Size
4 picoliter
Ink Capacity
130ml per color2
Ink Types
Dye/Pigment Reactive Ink
Color Set
Dye: Cyan, Magenta, Yellow, Black
Pigment: Matte Black (two channels)
Buffer/Ram
256 MB
Hard Drive
N/A
Media Width
Cut Sheet and Roll: 8" - 24"
Media Thickness
Top Loading Manual Feed: 0.07 - 0.8mm (2.8 - 31.4mil)
Front Loading Manual Feed: 0.5 - 1.5mm (19.6 - 59.0mil)
Roll: 0.07 - 0.8mm (2.8 - 31.4mil)
Maximum Roll Print Length
59 Feet (18 meters)3
Maximum Media Roll Diameter
5.9" (150mm)
Borderless Printing Width (Roll Media Only)
10" (254 mm), B4 (257 mm), A3+ (329 mm), 14" (356 mm), 16" (407 mm), A2 (420 mm), A2+/17" (432 mm), B2 (515 mm), A1 (594 mm), 24" (610 mm)
Paper-Feed Method
Roll Feed: One Roll, front output
Top Loading Manual Feed: One sheet, front output
Front Loading Manual Feed: One sheet, front output
Languages
Language: GARO (Canon Proprietary)
Noise Level (Approx.)
Operation: 52 dB (A) or less
Standby: 35 dB (A) or less
Acoustic Power: 6.6 Bels
Physical Dimensions
39.1" (H) x 39.3" (W) x 34.3" (D)
Weight
Approximately 132.3 lbs with stand
Power Source
AC-100-120V (50-60Hz)
Power Consumption
Maximum: 100W or less
Standby 6W or less
Power Off: 1W or less (Compliant with Executive Order of the President of the United States)
Operating Environment
Temperature: 59°-68° F (15°-30° C)
Relative Humidity: 10-80% (No Condensation)
User-replaceable items
Print Head (PF-03)
Maintenance Cartridge (MC-16)
Software Included
Canon Printer Driver, Digital Photo Front-Access Printer, Driver Extra Kit (Free Layout, imageRUNNER Linking Function), HDI Driver for AutoCAD4, PosterArtist Lite (PC only)
